Manufactured in the USA

All text and images contained in this document are proprietary and may not be shared, modified,

distributed, reproduced, or reused without the express written permission of EZ-ACCESS.

12963 REV 10-14-14

Installation Manual

Fortress OSHA Stair System

Adjustable Temporary Stair

Rated Load: 100 psf, 300 lbs. concentrated

3-Tread at 25.5”

3-Tread at 34”

4-Tread at 34”

4-Tread at 42.5”

1 2 3 4 5 6

Page 2 of 6 1. TOOLS TYPICALLY NEEDED:  Tape measure  Level  Ratchet wrench  1/2” socket (deep well)  9/16” socket (deep well) 2. INSPECT (

Page 3 of 6 FIG. 1 Part No. Fortress OSHA Stair Descriptions Diagram Letter 13193 3 Tread Platform (Includes Legs) A 13105 4 Tread Platform (Include

Page 4 of 6 4. INSTALLATION: 4.1. Rated Load: 100 psf, 300 lbs. concentrated. 4.2. OSHA Riser Safety Pins (FIG. 1D) must ALWAYS be installed in the

Page 5 of 6 FIG. 2 FIG. 3 FIG. 4

Page 6 of 6 5. OVERSIZED FEET INSTALLATION (OPTIONAL EQUIPMENT): 5.1. Loosen the leg adjustment bolts in each platform and riser corner pocket, but d
